Three-Layer Co-Extrusion High-Pressure Film Blowing Unit Configuration

Name: Three-Layer Co-Extrusion High-Pressure Film Blowing Unit Configuration
Brand: CHAOXIN
SKU: 00065
Rating: 4.1 (83 reviews)

Features

Main motor:Siemens(Germany) ,Brook(UK) ,GE(USA)

Suitable materials:LDPE/LLDPE/PBAT+PLA

Screw L/D:32:1/30:1

Inverter:ETD（USA）, Schneider（French）, ABB（Switzerland）

Temperature-controlled meter:Omron

Output:240kg/h; 350kg/h; 400kg/h

Inquire Now

Watch The Video

CX-1700 Three-Layer Co-Extrusion High-Pressure Film Blowing Unit Configuration

CE Certifed

CHAOXIN has a number of international certifications to ensure product quality.

Years Warranty

CHAOXIN offers a 3 years warranty on parts

Premium Service

CHAOXIN provides you with the most comprehensive service.

Product Specifications

MODEL	CX-ABC-1700 (WITH IBC)	CX-ABC-2200 (WITH IBC)	CX-ABC-2600 (WITH IBC)
Suitable materials	LDPE, LLDPE, PBAT+PLA	LDPE, LLDPE, PBAT+PLA	LDPE, LLDPE, PBAT+PLA
Film width	1000-1600mm	1300-2100mm	1800-2500mm
Film thickness	0.02-0.20mm	0.02-0.20mm	0.02-0.20mm
Max.extrusion output	240kg/h	350kg/h	400kg/h
Screw diameter	Φ60/Φ65/Φ60	Φ65/Φ70/Φ65	Φ75/Φ80/Φ75
Screw L/D	32:1/30:1	32:1/30:1	32:1/30:1
Gearbox	180*3	1802/2001	2002/2251
Main motor	22/30/22kw	30/37/30kw	45/55/45kw
Air blower	7.5kw	11kw	15kw
Average power consumption	85kw	110kw	140kw
Die diameter	350mm	500mm	550mm
Traction roller width	1700mm	2200mm	2600mm
Dimension/Weight	8.55.57.5m/15T	97.510.5m/20T	1010.512.5m/25T

Comparision

WHY CHOOSE US?

CATEGORY

Chaoxin

Others

1. Screws

⭐⭐⭐

Optimized screw raises the extrusion volume and using lifespan. Higher anti-corrupt and anti-grind ability.

Customized screw keyway and 30:1 or 32:1 L/D double alloy screws with vacuum fire treatment.

Only 28:1 or 30:1 L/D single alloy screw

2. Motor

⭐⭐⭐⭐

The motor operates with frequency conversion, which shows its advantages in terms of energy saving.

Imported from American GE or Germany SIEMENS (with a three-year warranty)

Other brands from China domestic market (with only one year warranty)

3. Up-traction

⭐⭐⭐⭐

The up-traction determines the Traction stability, plastic film flatness and embossing effect.

5-rollers traction, one embossing roller, one bending roller, one polyurethane roller and two traction rollers.

Three rollers or four rollers traction with normal rubber.

4. Frame

⭐⭐

The thick frame makes the machine more durable and reliable.

The square tubes of machines are all thickened with a diameter of 120mm.

The mainstream in the market is 80mm in diameter

5. Gear Box

⭐⭐⭐

External circulation oil cooling system and hard tooth ensures the high working speed and lifespan of the gear joint.

Xiaoshan brand hard tooth oil-cooled type, with filter, circulating oil and external cooling pump.

Soft tooth gear box Other brands of from China domestic market without external oil cooling system .

6. Heating

⭐⭐⭐⭐

Advanced heating is much better in terms of life, heating speed and heat preservation effect than stainless steel heating.

Aluminum heating, ceramic heating and more advanced infrared heating.

Traditional stainless steel heating.

7. Air ring

⭐⭐⭐⭐

The structurally optimized high-speed air ring reduces the wind resistance and make the change of wind volume gentle.

Italian designed high-speed double/ triple vent air ring.

Normal single, double vent air ring from domestic market.

8. Guarantee

⭐⭐⭐⭐

Chaoxin creates a precedent of guarantee period in this industry, which enables clients to get trully hassle-free products & sevice.

Main motor, fan, inverter, die head, gear box are guaranteed for three years.

Other manufacturers basically have a one-year warranty.

9. Production

⭐⭐⭐⭐⭐

5S management standards and high-end machining center equip Chaoxin with precision production capabilities and ensure product standards and quality.

5S management modern standardized workshop.

Traditional and chaotic production management.
